Generation & Storage
All-In-One Battery & Inverter
Our all-in-one modular battery and inverter system is designed to deliver dependable energy storage and power management.
Downloads
Download the datasheet
Share
Energy storage made easy
Available in two options
This modular battery and inverter is available in 6kW and 12kW options to cater to specific houses.
Reduces standard installation time
With its modular design, the All-In-One Inverter & Battery is easy to install and reduces installation time.
Speak to a member of our team today.
Technical Details
| Product Code | WDR-AB-0605-UK |
|---|---|
| Dimensions (W x D x H) | 730 x 205 x 929mm |
| Net Weight | 95kg |
| Max AC Output Power | 5kW |
| Max Charging/ Discharging Power | 3kW |
| Operating Temp | -20°C – 55°C |
| Operating Power Consumption | 545 mA |
| Mounting Options | Wall and floor |
| Communication Module | WiFi |
| Life Expectancy | 15 years |
| Ingress Protection rate/IP | IP65 |
| Standby Power Consumption | <30W |
| Product Code | WDR-AB-1206-UK |
|---|---|
| Dimensions (W x D x H) | 730 x 205 x 1399mm |
| Net Weight | 154kg |
| Max AC Output Power | 6kW |
| Max Charging/ Discharging Power | 6kW |
| Operating Temp | -20°C – 55°C |
| Operating Power Consumption | 545 mA |
| Mounting Options | Wall and floor |
| Communication Module | WiFi |
| Life Expectancy | 15 years |
| Ingress Protection rate/IP | IP65 |
| Standby Power Consumption | <30W |
| Product Code | WDR-HT-200-UK |
|---|---|
| Dimensions (W x D x H) | 620 x 620 x 1638mm |
| Net Weight | 105kg |
| Heating Capacity | 2.2kW |
| Storage Size | 200 litres |
| COP | 4.15kW |
| Output Water Temp | 55°C (Max.75°C) |
| Power Input | 530W |
| Max Power Input | 3000W |
| Refrigerant type | R290 |
| Running Ambient Temp | -7°C – 43°C |
| Power Supply | 220V/50Hz |
| Certification | CE / UKCA |
| Product Code | WDR-HT-250-UK |
|---|---|
| Dimensions (W x D x H) | 620 x 620 x 1638mm |
| Net Weight | 115kg |
| Heating Capacity | 2.2kW |
| Storage Size | 250 litres |
| COP | 4.15kW |
| Output Water Temp | 55°C (Max.75°C) |
| Power Input | 530W |
| Max Power Input | 3000W |
| Refrigerant type | R290 |
| Running Ambient Temp | -7°C – 43°C |
| Power Supply | 220V/50Hz |
| Certification | CE / UKCA |
| Product Code | WDR-HT-300-UK |
|---|---|
| Dimensions (W x D x H) | 620 x 620 x 2038mm |
| Net Weight | 130kg |
| Heating Capacity | 2.2kW |
| Storage Size | 300 litres |
| COP | 4.15kW |
| Output Water Temp | 55°C (Max.75°C) |
| Power Input | 530W |
| Max Power Input | 3000W |
| Refrigerant type | R290 |
| Running Ambient Temp | -7°C – 43°C |
| Power Supply | 220V/50Hz |
| Certification | CE / UKCA |
